PRODUCTS

ASEA Power’s wide portfolio of products is built to exceed industry safety standards. With fully-shielded isolation transformers protecting each product, no matter your needs, ASEA Power has you covered.

REQUEST A QUOTE

OUR PRODUCTS

Explore our product offerings in depth to identify the right series for your needs.

Standard Series

​Our standard product series offers various options, including dual or single cord and single or three phase capability. Built with popular stainless-steel enclosures, the Standard Series can be built to various cabinet styles and can be completely customized to fit virtually any space. 

Q Series

The Q Series features a modular configuration for easy installation and service. Additionally, units with three phase input feature reduced mode capability, allowing them to operate at two-thirds capacity should one module be compromised. The Q Series features powder-coated aluminum covers and chassis, making it incredibly lightweight. The Q Series can also be built in a two-piece configuration (QTP).

NV Series

The NV series operates on three phase modules, allowing for reduced capacity mode operation if a single module is compromised. The NV series is built in a vertical configuration and is often paired with a heat exchanger.

*Contact us for specs.

TP Series

​The Two-Piece Series breaks a standard unit into small, manageable pieces for ease of installation in vessels with limited space. The TP series features a stainless-steel chassis and powder-coated aluminum covers.

AC Series

​The AC Series are some of the lightest and most compact shore power converters available on the market. Units from the Standard Series have been installed in thousands of vessels around the globe and offer high power density. This series features a stainless-steel chassis and powder-coated aluminum covers.

LC Series

​For those with limited space, the Liquid Cooled Series offers a compact solution with no requirement for Air Flow Ventilation. The LC Series features a stainless-steel chassis and powder-coated aluminum covers.

NVHE Series

​The Vertical Heat Exchanger Series utilizes the vessel’s existing chilled water system to remove heat. VHE Series converters can be isolated from the ship’s engine room environment, so customers do not need to consider the engine room temperature when installing. There is also an optional conversion to the air-cooled system available if the vessel’s chilled water system is unavailable. The VHE Series features a stainless-steel chassis and powder-coated aluminum covers.

*Contact us for specs.

DOCK BOOST TRANSFORMERS (DBT)

​ASEA Power’s Dock Boost Transformers are intelligent voltage-correcting isolation transformers operating at a range from 167V-270V input. The DBT systems corrects the power input to usable power.

Available in 12kVA, with a 24kVA option in development. ​​

CHOOSING A SHORE POWER CONVERTER

This graphic explains the different elements of each ASEA Power product name.
Use it to find the ASEA Power shore power converter for you.

SHORE CORD CAPACITIES

Use the below tables to help guide your selection of an appropriately sized shore power converter.

Voltage 16A 32A 50A 63A 100A 125A
208V 3.3kVA 6.7kVA 10.4kVA 13.1kVA 20.8kVA 26.0kVA
230V 3.7kVA 7.4kVA 11.5kVA 14.5kVA 23.0kVA 28.8kVA
204V 3.8kVA 7.7kVA 12.0kVA 15.1kVA 24.0kVA 30.0kVA
400V 6.4kVA 12.8kVA 20.0kVA 25.2kVA 40.0kVA 50.0kVA
440V 7.0kVA 14.1kVA 22.0kVA 27.7kVA 44.0kVA 55.0kVA

Voltage 16A 32A 50A 63A 100A 125A
208V 5.8kVA 11.5kVA 18.0kVA 22.7kVA 36.0kVA 45.0kVA
230V 6.4kVA 12.7kVA 19.9kVA 25.1kVA 39.8kVA 49.7kVA
204V 6.6kVA 13.3kVA 20.8kVA 26.2kVA 41.5kVA 51.9kVA
400V 11.1kVA 22.1kVA 34.6kVA 43.6kVA 69.2kVA 86.5kVA
440V 12.2kVA 24.4kVA 38.1kVA 48.0kVA 76.1kVA 95.2kVA

Style Height (mm/in) Width (mm/in) Depth (mm/in) Air Flow In Air Flow Out Notes
A 510 / 20″ 585 / 23″ 255 / 10″ Bottom Side Bulkhead mount
B 570 / 22.4″ 740 / 29.13 305 / 12″ Bottom Side Bulkhead mount
C 1045 / 41″ 432 / 17″ 770 / 30.25″ Back Front
D 1045 / 41″ 607 / 23.875″ 770 / 30.25″ Back Front Top or front display
E 1270 / 50″ 607 / 23.875″ 770 / 30.25″ Back Front Top or front display
F 1045 / 41″ 458 / 18″ 770 / 30.25″ Back Front Front display
G 1270 / 50″ 607 / 23.875″ 864 / 34″ Back Front Top or front display
H 635 / 25″ 607 / 23.875″ 947 / 37.25″ Back Front Top or front display
I 1426 / 56.125″ 635 / 25″ 508 / 20″ Front, bottom, side & rear Top side or top
J 1655 / 65.125″ 635 / 25″ 508 / 20″ Front, bottom, side & rear Top side or top
K 1245 / 49″ 607 / 23.875″ 712 / 28″ Bottom, side & rear Top
L 1465 / 57.675″ 458 / 18″ 534 / 21″ Front, bottom, side Top
M 635 / 25″ 607 / 23.875″ 947 / 37.25″ Back Front Top, front or side display
N 1347 / 53″ 1521 / 59.875″ 254 / 10″ Front Top Wall hugger
O 356 / 14″ 432 / 17″ 610 / 24″ Convection (no fans) Convection (no fans) Transformer Cabinet
O 610 / 24″ 610 / 24″ 610 / 24″ Right side Left side Control Cabinet
R 1654 / 65.125″ 645 / 25″ 584 / 23″ Side & rear Front Top or front display
S 1067 / 42″ 602 / 23.688″ 762 / 30″ Liquid cooled Liquid cooled
U 1194 / 47″ 680 / 26.75″ 878 / 34.53″ Liquid cooled Liquid cooled
Q1 851 / 33.5″ 350 / 13.75″ 664 / 26.11″ Rear Front Front display
Q2 1016 / 40″ 350 / 13.75″ 664 / 26.11″ Rear Front Front display
Q3 1197 / 47.1″ 488 / 19.2″ 643 / 25.3″ Rear Front Front display
Q4 953 / 37.5″ 488 / 19.2″ 643 / 25.3″ Rear Front Front display
Q5 1080 / 42.5″ 488 / 19.2″ 643 / 25.3″ Rear Front Front display
Q6 1403 / 55.2″ 590 / 23.2″ 897 / 35.3″ Rear Front Front display
Q7 1580 / 62.2″ 590 / 23.2″ 897 / 35.3″ Rear Front Front display

Single Phase

Voltage 16A 32A 50A 63A 100A 125A
208V 3.3kVA 6.7kVA 10.4kVA 13.1kVA 20.8kVA 26.0kVA
230V 3.7kVA 7.4kVA 11.5kVA 14.5kVA 23.0kVA 28.8kVA
204V 3.8kVA 7.7kVA 12.0kVA 15.1kVA 24.0kVA 30.0kVA
400V 6.4kVA 12.8kVA 20.0kVA 25.2kVA 40.0kVA 50.0kVA
440V 7.0kVA 14.1kVA 22.0kVA 27.7kVA 44.0kVA 55.0kVA

Three Phase

Voltage 16A 32A 50A 63A 100A 125A
208V 5.8kVA 11.5kVA 18.0kVA 22.7kVA 36.0kVA 45.0kVA
230V 6.4kVA 12.7kVA 19.9kVA 25.1kVA 39.8kVA 49.7kVA
204V 6.6kVA 13.3kVA 20.8kVA 26.2kVA 41.5kVA 51.9kVA
400V 11.1kVA 22.1kVA 34.6kVA 43.6kVA 69.2kVA 86.5kVA
440V 12.2kVA 24.4kVA 38.1kVA 48.0kVA 76.1kVA 95.2kVA

Cabinet Dimensions

Style Height (mm/in) Width (mm/in) Depth (mm/in) Air Flow In Air Flow Out Notes
A 510 / 20″ 585 / 23″ 255 / 10″ Bottom Side Bulkhead mount
B 570 / 22.4″ 740 / 29.13 305 / 12″ Bottom Side Bulkhead mount
C 1045 / 41″ 432 / 17″ 770 / 30.25″ Back Front
D 1045 / 41″ 607 / 23.875″ 770 / 30.25″ Back Front Top or front display
E 1270 / 50″ 607 / 23.875″ 770 / 30.25″ Back Front Top or front display
F 1045 / 41″ 458 / 18″ 770 / 30.25″ Back Front Front display
G 1270 / 50″ 607 / 23.875″ 864 / 34″ Back Front Top or front display
H 635 / 25″ 607 / 23.875″ 947 / 37.25″ Back Front Top or front display
I 1426 / 56.125″ 635 / 25″ 508 / 20″ Front, bottom, side & rear Top side or top
J 1655 / 65.125″ 635 / 25″ 508 / 20″ Front, bottom, side & rear Top side or top
K 1245 / 49″ 607 / 23.875″ 712 / 28″ Bottom, side & rear Top
L 1465 / 57.675″ 458 / 18″ 534 / 21″ Front, bottom, side Top
M 635 / 25″ 607 / 23.875″ 947 / 37.25″ Back Front Top, front or side display
N 1347 / 53″ 1521 / 59.875″ 254 / 10″ Front Top Wall hugger
O 356 / 14″ 432 / 17″ 610 / 24″ Convection (no fans) Convection (no fans) Transformer Cabinet
O 610 / 24″ 610 / 24″ 610 / 24″ Right side Left side Control Cabinet
R 1654 / 65.125″ 645 / 25″ 584 / 23″ Side & rear Front Top or front display
S 1067 / 42″ 602 / 23.688″ 762 / 30″ Liquid cooled Liquid cooled
U 1194 / 47″ 680 / 26.75″ 878 / 34.53″ Liquid cooled Liquid cooled
Q1 851 / 33.5″ 350 / 13.75″ 664 / 26.11″ Rear Front Front display
Q2 1016 / 40″ 350 / 13.75″ 664 / 26.11″ Rear Front Front display
Q3 1197 / 47.1″ 488 / 19.2″ 643 / 25.3″ Rear Front Front display
Q4 953 / 37.5″ 488 / 19.2″ 643 / 25.3″ Rear Front Front display
Q5 1080 / 42.5″ 488 / 19.2″ 643 / 25.3″ Rear Front Front display
Q6 1403 / 55.2″ 590 / 23.2″ 897 / 35.3″ Rear Front Front display
Q7 1580 / 62.2″ 590 / 23.2″ 897 / 35.3″ Rear Front Front display

These tables provide an approximate indication of the amount of kVA capacity of different amperage shore cords at common worldwide voltages.

FULL TECHNICAL
PRODUCT LIST

Download a full list of our converter and power management system product portfolios for information on model numbers, power level, input and output needs, cabinet specs, shore cords and mounting options.
