Standard Series
(24–54 kVA)

The Standard Series is customizable to fit virtually any space. Enclosure options include two-piece, wall hugger, and foot locker variations. Made from stainless steel, the unit is durable, reliable, and less susceptible to electromagnetic interference. Every unit is equipped with an isolation transformer to protect against galvanic corrosion, polarization, and fault current electrocution.

In addition to the basic function of power conversion, these converters provide the user with a ophisticated power analysis and monitoring capability. Various displays are selected through a long-life, sealed membrane switch panel. All front panel information is available through the serial port for remote display, status, and diagnostics.

Features

  • Auto-restart from shore brownout or blackout
  • Conformal coated printed circuit boards
  • Front panel display console
  • Minimal harmonic distortion
  • Reverse polarization prevention
  • Galvanic corrosion protection
  • Global support network
  • Precision regulation

COMMONLY INSTALLED ON

Multiple Enclosure Styles

Customizable to fit most available spaces

Dual Conversion Technology

Precision regulation and minimal harmonic distortion

Stainless Steel & Aluminum

Power coated for ultimate durability and protection

SPECIFICATIONS

DOWNLOAD PDF
Model AC24 DSC (Dual Shore Cord) AC30 DSC (Dual Shore Cord) AC36 DSC (Dual Shore Cord)
Part Number
607784
607785
607786
Input Power Form
Single
Single
Single
Input Voltage
170-520 V
170-520 V
170-520 V
Input Frequency
40-70 Hz
40-70 Hz
40-70 Hz
Power Factor
> 0.98 @ rated load
> 0.98 @ rated load
> 0.98 @ rated load
Auto Restart
Standard
Standard
Standard
Shore Cord Input
Dual
Dual
Dual
Output Power Rating
24 kVA
24 kVA
24 kVA
Output Power Form
Single, Split
Single, Split
Single, Split
Upgradeability
30 or 36 kVA
30 or 36 kVA
30 or 36 kVA
OUTPUT VOLTAGE
220, 230, 240, 110/220, 115/230, 120/240 V
220, 230, 240, 110/220, 115/230, 120/240 V
220, 230, 240, 110/220, 115/230, 120/240 V
Output Frequency
50 Hz / 60 Hz
50 Hz / 60 Hz
50 Hz / 60 Hz
Conversion Efficiency
91% @ rated load
91% @ rated load
91% @ rated load
Cooling
Air
Air
Air
Mounting
Floor
Floor
Floor
Series
Standard
StandardStandard
Standard
Enclosure Style
Standard
Standard
Standard
Legacy Enclosure
F
F
F
Weight
275 kg / 606 lbs
285 kg / 628 lbs
285 kg / 628 lbs
Height
104.0 cm / 40.9 in
104.0 cm / 40.9 in
104.0 cm / 40.9 in
Width
45.7 cm / 18.0 in
45.7 cm / 18.0 in
45.7 cm / 18.0 in
Depth
76.8 cm / 30.2 in
76.8 cm / 30.2 in
76.8 cm / 30.2 in
Model AC24TP DSC (Dual Shore Cord) AC30TP DSC (Dual Shore Cord) AC36TP DSC (Dual Shore Cord)
Part Number
607582
607583
607584
Input Power Form
Single
Single
Single
Input Voltage
170-520 V
170-520 V
170-520 V
Input Frequency
40-70 Hz
40-70 Hz
40-70 Hz
Power Factor
> 0.98 @ rated load
> 0.98 @ rated load
> 0.98 @ rated load
Auto Restart
Standard
Standard
Standard
Shore Cord Input
Dual
Dual
Dual
Output Power Rating
24 kVA
24 kVA
24 kVA
Output Power Form
Single, Split
Single, Split
Single, Split
Upgradeability
30 or 36 kVA
30 or 36 kVA
30 or 36 kVA
OUTPUT VOLTAGE
220, 230, 240, 110/220, 115/230, 120/240 V V
220, 230, 240, 110/220, 115/230, 120/240 V
220, 230, 240, 110/220, 115/230, 120/240 V
Output Frequency
50/60 Hz
50/60 Hz
50/60 Hz
Output Current
100 A @ 0.85 p.f.
100 A @ 0.85 p.f.
100 A @ 0.85 p.f.
Efficiency
91% @ rated load
91% @ rated load
91% @ rated load
Cooling
Air
Air
Air
Mounting
Floor
Floor
Floor
Series
Standard
StandardStandard
Standard
Enclosure Style
Two-Piece
Two-Piece
Two-Piece
Legacy Enclosure
O
O
O
Weight
128, 163 kg / 282, 360 lbs
128, 163 kg / 282, 360 lbs
128, 163 kg / 282, 360 lbs
Height
61.0, 37.1 cm / 24.0, 14.6 in
61.0, 37.1 cm / 24.0, 14.6 in
61.0, 37.1 cm / 24.0, 14.6 in
Width
61.0, 43.2 cm / 24.0, 17.0 in
61.0, 43.2 cm / 24.0, 17.0 in
61.0, 43.2 cm / 24.0, 17.0 in
Depth
61.0, 64.8 cm / 24.0, 25.5 in
61.0, 64.8 cm / 24.0, 25.5 in
61.0, 64.8 cm / 24.0, 25.5 in
Model AC25-1 AC25TP-1 AC25FL-1 AC25WH-1
Part Number
607525
607570
632521
604539
Input Power Form
Single, Three
Single, Three
Single, Three
Single, Three
Input Voltage
170-520 V
170-520 V
170-520 V
170-520 V
Input Frequency
40-70 Hz
40-70 Hz
40-70 Hz
40-70 Hz
Power Factor
> 0.99 @ rated load
> 0.99 @ rated load
> 0.99 @ rated load
> 0.99 @ rated load
Auto Restart
Standard
Standard
Standard
Standard
Shore Cord Input
Single
Single
Single
Single
Output Power Rating
25 kVA
25 kVA
25 kVA
25 kVA
Output Power Form
Single, Split
Single, Split
Single, Split
Single, Split
Upgradeability
30 or 36 kVA
30 or 36 kVA
30 or 36 kVA
30 or 36 kVA
Output Voltage
220, 230, 240, 120/240 V
220, 230, 240, 120/240 V
220, 230, 240, 120/240 V
220, 230, 240, 120/240 V
Output Frequency
50/60 Hz
50/60 Hz
50/60 Hz
50/60 Hz
Output Current
See table below
See table below
See table below
See table below
Efficiency
91% @ rated load
91% @ rated load
91% @ rated load
91% @ rated load
Cooling
Air
Air
Air
Air
Mounting
Floor
Floor
Floor
Floor
Series
Standard
Standard
Standard
Standard
Enclosure Style
Standard
Two-Piece
Foot Locker
Wall Hugger
Legacy Enclosure
F
O
FL
N
Weight
323 kg / 712 lbs
139, 191 kg / 306, 421 lbs
315 kg / 694 lbs
333 kg / 734 lbs
Height
104.0 cm / 40.9 in
61.0, 37.1 cm / 24.0, 14.6 in
61.0 cm / 24.0 in
151.5 cm / 59.6 in
Width
45.7 cm / 18.0 in
61.0, 43.2 cm / 24.0, 17.0 in
92.4 cm / 36.4 in
151.9 cm / 59.8 in
Depth
76.8 cm / 30.2 in
61.0, 64.8 cm / 24.0, 25.5 in
64.7 cm / 25.5 in
25.4 cm / 10.0 in
Model AC25-3 AC25TP-3 AC25FL-3 AC25WH-3
Part Number
607521
607573
632524
Contact Us
Input Power Form
Single, Three
Single, Three
Single, Three
Single, Three
Input Voltage
170-520 V
170-520 V
170-520 V
170-520 V
Input Frequency
40-70 Hz
40-70 Hz
40-70 Hz
40-70 Hz
Power Factor
> 0.99 @ rated load
> 0.99 @ rated load
> 0.99 @ rated load
> 0.99 @ rated load
Auto Restart
Standard
Standard
Standard
Standard
Shore Cord Input
Single
Single
Single
Single
Output Power Rating
25 kVA
25 kVA
25 kVA
25 kVA
Output Power Form
Three
Three
Three
Three
Upgradeability
30 or 36 kVA
30 or 36 kVA
30 or 36 kVA
30 or 36 kVA
Output Voltage
220, 230, 240, 120/240 V
220, 230, 240, 120/240 V
220, 230, 240, 120/240 V
220, 230, 240, 120/240 V
Output Frequency
50/60 Hz
50/60 Hz
50/60 Hz
50/60 Hz
Output Current
See table below
See table below
See table below
See table below
Efficiency
91% @ rated load
91% @ rated load
91% @ rated load
91% @ rated load
Cooling
Air
Air
Air
Air
Mounting
Floor
Floor
Floor
Floor
Series
Standard
Standard
Standard
Standard
Enclosure Style
Standard
Two-Piece
Foot Locker
Wall Hugger
Legacy Enclosure
F
O
FL
N
Weight
323 kg / 712 lbs
139, 191 kg / 306, 421 lbs
315 kg / 694 lbs
333 kg / 734 lbs
Height
104.0 cm / 40.9 in
61.0, 37.1 cm / 24.0, 14.6 in
61.0 cm / 24.0 in
151.5 cm / 59.6 in
Width
45.7 cm / 18.0 in
61.0, 43.2 cm / 24.0, 17.0 in
92.4 cm / 36.4 in
151.9 cm / 59.8 in
Depth
76.8 cm / 30.2 in
61.0, 64.8 cm / 24.0, 25.5 in
64.7 cm / 25.5 in
25.4 cm / 10.0 in
Model AC30-1 AC30TP-1 AC30FL-1 AC30WH-1
Part Number
607526
607571
632522
N/A
Input Power Form
Single, Three
Single, Three
Single, Three
Single, Three
Input Voltage
170-520 V
170-520 V
170-520 V
170-520 V
Input Frequency
40-70 Hz
40-70 Hz
40-70 Hz
40-70 Hz
Power Factor
> 0.99 @ rated load
> 0.99 @ rated load
> 0.99 @ rated load
> 0.99 @ rated load
Auto Restart
Standard
Standard
Standard
Standard
Shore Cord Input
Single
Single
Single
Single
Output Power Rating
30 kVA
30 kVA
30 kVA
30 kVA
Output Power Form
Single, Split
Single, Split
Single, Split
Single, Split
Upgradeability
36 kVA
36 kVA
36 kVA
36 kVA
Output Voltage
220, 230, 240, 120/240 V
220, 230, 240, 120/240 V
220, 230, 240, 120/240 V
220, 230, 240, 120/240 V
Output Frequency
50/60 Hz
50/60 Hz
50/60 Hz
50/60 Hz
Output Current
See table below
See table below
See table below
See table below
Efficiency
91% @ rated load
91% @ rated load
91% @ rated load
91% @ rated load
Cooling
Air
Air
Air
Air
Mounting
Floor
Floor
Floor
Floor
Series
Standard
Standard
Standard
Standard
Enclosure Style
Standard
Two-Piece
Foot Locker
Wall Hugger
Legacy Enclosure
F
O
FL
N
Weight
323 kg / 712 lbs
139, 191 kg / 306, 421 lbs
315 kg / 694 lbs
333 kg / 734 lbs
Height
104.0 cm / 40.9 in
61.0, 37.1 cm / 24.0, 14.6 in
61.0 cm / 24.0 in
151.5 cm / 59.6 in
Width
45.7 cm / 18.0 in
61.0, 43.2 cm / 24.0, 17.0 in
92.4 cm / 36.4 in
151.9 cm / 59.8 in
Depth
76.8 cm / 30.2 in
61.0, 64.8 cm / 24.0, 25.5 in
64.7 cm / 25.5 in
25.4 cm / 10.0 in
Model AC30-3 AC30TP-3 AC30FL-3 AC30WH-3
Part Number
607522
607574
632525
contact us
Input Power Form
Single, Three
Single, Three
Single, Three
Single, Three
Input Voltage
170-520 V
170-520 V
170-520 V
170-520 V
Input Frequency
40-70 Hz
40-70 Hz
40-70 Hz
40-70 Hz
Power Factor
> 0.99 @ rated load
> 0.99 @ rated load
> 0.99 @ rated load
> 0.99 @ rated load
Auto Restart
Standard
Standard
Standard
Standard
Shore Cord Input
Single
Single
Single
Single
Output Power Rating
30 kVA
30 kVA
30 kVA
30 kVA
Output Power Form
Three
Three
Three
Three
Upgradeability
36 kVA
36 kVA
36 kVA
36 kVA
Output Voltage
120/208, 127/220, 220/380, 230/400, 240/416 V
120/208, 127/220, 220/380, 230/400, 240/416 V
120/208, 127/220, 220/380, 230/400, 240/416 V
120/208, 127/220, 220/380, 230/400, 240/416 V
Output Frequency
50/60 Hz
50/60 Hz
50/60 Hz
50/60 Hz
Output Current
See table below
See table below
See table below
See table below
Efficiency
91% @ rated load
91% @ rated load
91% @ rated load
91% @ rated load
Cooling
Air
Air
Air
Air
Mounting
Floor
Floor
Floor
Floor
Series
Standard
Standard
Standard
Standard
Enclosure Style
Standard
Two-Piece
Foot Locker
Wall Hugger
Legacy Enclosure
F
O
FL
N
Weight
323 kg / 712 lbs
139, 191 kg / 306, 421 lbs
315 kg / 694 lbs
333 kg / 734 lbs
Height
104.0 cm / 40.9 in
61.0, 37.1 cm / 24.0, 14.6 in
61.0 cm / 24.0 in
151.5 cm / 59.6 in
Width
45.7 cm / 18.0 in
61.0, 43.2 cm / 24.0, 17.0 in
92.4 cm / 36.4 in
151.9 cm / 59.8 in
Depth
76.8 cm / 30.2 in
61.0, 64.8 cm / 24.0, 25.5 in
64.7 cm / 25.5 in
25.4 cm / 10.0 in
Model AC36-1 AC36TP-1 AC36FL-1 AC36WH-1
Part Number
607541
607572
632523
604544
Input Power Form
Single, Three
Single, Three
Single, Three
Single, Three
Input Voltage
170-520 V
170-520 V
170-520 V
170-520 V
Input Frequency
40-70 Hz
40-70 Hz
40-70 Hz
40-70 Hz
Power Factor
> 0.99 @ rated load
> 0.99 @ rated load
> 0.99 @ rated load
> 0.99 @ rated load
Auto Restart
Standard
Standard
Standard
Standard
Shore Cord Input
Single
Single
Single
Single
Output Power Rating
36 kVA
36 kVA
36 kVA
36 kVA
Output Power Form
Single, Split
Single, Split
Single, Split
Single, Split
Upgradeability
N/A
N/A
N/A
N/A
Output Voltage
220, 230, 240, 120/240 V
220, 230, 240, 120/240 V
220, 230, 240, 120/240 V
220, 230, 240, 120/240 V
Output Frequency
50/60 Hz
50/60 Hz
50/60 Hz
50/60 Hz
Output Current
See table below
See table below
See table below
See table below
Efficiency
91% @ rated load
91% @ rated load
91% @ rated load
91% @ rated load
Cooling
Air
Air
Air
Air
Mounting
Floor
Floor
Floor
Floor
Series
Standard
Standard
Standard
Standard
Enclosure Style
Standard
Two-Piece
Foot Locker
Wall Hugger
Legacy Enclosure
F
O
FL
N
Weight
323 kg / 712 lbs
139, 191 kg / 306, 421 lbs
315 kg / 694 lbs
333 kg / 734 lbs
Height
104.0 cm / 40.9 in
61.0, 37.1 cm / 24.0, 14.6 in
61.0 cm / 24.0 in
151.5 cm / 59.6 in
Width
45.7 cm / 18.0 in
61.0, 43.2 cm / 24.0, 17.0 in
92.4 cm / 36.4 in
151.9 cm / 59.8 in
Depth
76.8 cm / 30.2 in
61.0, 64.8 cm / 24.0, 25.5 in
64.7 cm / 25.5 in
25.4 cm / 10.0 in
Model AC36-3 AC36TP-3 AC36FL-3 AC36WH-3
Part Number
607542
607575
632526
604557
Input Power Form
Single, Three
Single, Three
Single, Three
Single, Three
Input Voltage
170-520 V
170-520 V
170-520 V
170-520 V
Input Frequency
40-70 Hz
40-70 Hz
40-70 Hz
40-70 Hz
Power Factor
> 0.99 @ rated load
> 0.99 @ rated load
> 0.99 @ rated load
> 0.99 @ rated load
Auto Restart
Standard
Standard
Standard
Standard
Shore Cord Input
Single
Single
Single
Single
Output Power Rating
36 kVA
36 kVA
36 kVA
36 kVA
Output Power Form
Three
Three
Three
Three
Upgradeability
N/A
N/A
N/A
N/A
Output Voltage
120/208, 127/220, 220/380, 230/400, 240/416 V
120/208, 127/220, 220/380, 230/400, 240/416 V
120/208, 127/220, 220/380, 230/400, 240/416 V
120/208, 127/220, 220/380, 230/400, 240/416 V
Output Frequency
50/60 Hz
50/60 Hz
50/60 Hz
50/60 Hz
Output Current
See table below
See table below
See table below
See table below
Efficiency
91% @ rated load
91% @ rated load
91% @ rated load
91% @ rated load
Cooling
Air
Air
Air
Air
Mounting
Floor
Floor
Floor
Floor
Series
Standard
Standard
Standard
Standard
Enclosure Style
Standard
Two-Piece
Foot Locker
Wall Hugger
Legacy Enclosure
F
O
FL
N
Weight
323 kg / 712 lbs
139, 191 kg / 306, 421 lbs
315 kg / 694 lbs
333 kg / 734 lbs
Height
104.0 cm / 40.9 in
61.0, 37.1 cm / 24.0, 14.6 in
61.0 cm / 24.0 in
151.5 cm / 59.6 in
Width
45.7 cm / 18.0 in
61.0, 43.2 cm / 24.0, 17.0 in
92.4 cm / 36.4 in
151.9 cm / 59.8 in
Depth
76.8 cm / 30.2 in
61.0, 64.8 cm / 24.0, 25.5 in
64.7 cm / 25.5 in
25.4 cm / 10.0 in
Model AC45-1 AC45WH-1 AC45-3 AC45WH-3
Part Number
604515
604545
604512
604553
Input Power Form
Single, Three
Single, Three
Single, Three
Single, Three
Input Voltage
170-520 V
170-520 V
170-520 V
170-520 V
Input Frequency
40-70 Hz
40-70 Hz
40-70 Hz
40-70 Hz
Power Factor
> 0.99 @ rated load
> 0.99 @ rated load
> 0.99 @ rated load
> 0.99 @ rated load
Auto Restart
Standard
Standard
Standard
Standard
Shore Cord Input
Single
Single
Single
Single
Output Power Rating
45 kVA
45 kVA
45 kVA
45 kVA
Output Power Form
Single, Split
Single, Split
Single, Split
Single, Split
Upgradeability
54 kVA
54 kVA
54 kVA
54 kVA
Output Voltage
220, 230, 240, 120/240 V
220, 230, 240, 120/240 V
220, 230, 240, 120/240 V
220, 230, 240, 120/240 V
Output Frequency
50/60 Hz
50/60 Hz
50/60 Hz
50/60 Hz
Output Current
See table below
See table below
See table below
See table below
Efficiency
91% @ rated load
91% @ rated load
91% @ rated load
91% @ rated load
Cooling
Air
Air
Air
Air
Mounting
Floor
Floor
Floor
Floor
Series
Standard
Standard
Standard
Standard
Enclosure Style
Standard
Wall Hugger
Standard
Wall Hugger
Legacy Enclosure
D
N
D
N
Weight
386 kg / 851 lbs
404 kg / 891 lbs
386 kg / 851 lbs
404 kg / 891 lbs
Height
104.1 cm / 41.0 in
151.5 cm / 59.6 in
104.1 cm / 41.0 in
151.5 cm / 59.6 in
Width
60.7 cm / 23.9 in
151.9 cm / 59.8 in
60.7 cm / 23.9 in
151.9 cm / 59.8 in
Depth
76.8 cm / 30.2 in
25.4 cm / 10 in
76.8 cm / 30.2 in
25.4 cm / 10 in
Model AC54-1 AC54WH-1 AC54-3 AC54WH-3
Part Number
604516
604546
604513
604569
Input Power Form
Single, Three
Single, Three
Single, Three
Single, Three
Input Voltage
170-520 V
170-520 V
170-520 V
170-520 V
Input Frequency
40-70 Hz
40-70 Hz
40-70 Hz
40-70 Hz
Power Factor
> 0.99 @ rated load
> 0.99 @ rated load
> 0.99 @ rated load
> 0.99 @ rated load
Auto Restart
Standard
Standard
Standard
Standard
Shore Cord Input
Single
Single
Single
Single
Output Power Rating
54 kVA
54 kVA
54 kVA
54 kVA
Output Power Form
Single, Split
Single, Split
Three
Three
Upgradeability
N/A
N/A
N/A
N/A
Output Voltage
220, 230, 240, 120/240 V
220, 230, 240, 120/240 V
120/208, 127/220, 220/380, 230/400, 240/416 V
120/208, 127/220, 220/380, 230/400, 240/416 V
Output Frequency
50/60 Hz
50/60 Hz
50/60 Hz
50/60 Hz
Output Current
See table below
See table below
See table below
See table below
Efficiency
91% @ rated load
91% @ rated load
91% @ rated load
91% @ rated load
Cooling
Air
Air
Air
Air
Mounting
Floor
Floor
Floor
Floor
Series
Standard
Standard
Standard
Standard
Enclosure Style
Standard
Wall Hugger
Standard
Wall Hugger
Legacy Enclosure
D
N
D
N
Weight
404 kg / 891 lbs
404 kg / 891 lbs
404 kg / 891 lbs
404 kg / 891 lbs
Height
104.1 cm / 41.0 in
151.5 cm / 59.6 in
104.1 cm / 41.0 in
151.5 cm / 59.6 in
Width
60.7 cm / 23.9 in
151.9 cm / 59.8 in
60.7 cm / 23.9 in
151.9 cm / 59.8 in
Depth
76.8 cm / 30.2 in
25.4 cm / 10 in
76.8 cm / 30.2 in
25.4 cm / 10 in
Output Form 25 kVA 30 kVA 36 kVA 45 kVA 54 kVA
1 Ø, 220 V
114 A/Ø
136 A/Ø
164 A/Ø
205 A/Ø
245 A/Ø
1 Ø, 230 V
109 A/Ø
130 A/Ø
157 A/Ø
196 A/Ø
235 A/Ø
1 Ø, 240 V
104 A/Ø
125 A/Ø
150 A/Ø
187 A/Ø
225 A/Ø
2 Ø, 120/240 V
104 A/Ø
125 A/Ø
150 A/Ø
187 A/Ø
225 A/Ø
3 Ø, 120/208 V
70 A/Ø
83 A/Ø
100 A/Ø
125 A/Ø
150 A/Ø
3 Ø, 127/220 V
66 A/Ø
79 A/Ø
94 A/Ø
118 A/Ø
142 A/Ø
3 Ø, 220/380 V
38 A/Ø
45 A/Ø
55 A/Ø
68 A/Ø
81 A/Ø
3 Ø, 230/400 V
36 A/Ø
43 A/Ø
52 A/Ø
65 A/Ø
78 A/Ø
3 Ø, 240/416 V
35 A/Ø
42 A/Ø
50 A/Ø
63 A/Ø
75 A/Ø
3 Ø, 254/440 V
–
–
–
59 A/Ø
71 A/Ø
